Huge Volume Infusion Compact Line

This line is composed of HHGP bottle feeding machine,HHXW prewashing machine,HHQCT ultrasonic cylinder washing machine,HHG-S filling and stoppering machine and HHZ positioned rotary capping machine. This line is applied to infusion filling in pharmaceutical factory,and large volume injection filling in animal pharmaceutical factory.Only changing some format parts the machine could fit 500 1000ml plastic or glass bottle.And it could be suitable for creaming agent,bacteria,alcohol of food industry.If adopt the traditional reversing edge stopper,extra equipment must be added. There are 2 different type of structure for 40 60bottles/min and 80 120bottles/min. This machine can provide you with CE certification. Main Technical Parameter 1.Packing Meterial: 50 500mlType A or B infusion bottle.(GB2639-90) Reversing edge stopper(GB9890-88) AL cap (GB5197-96) 2.Productive Capacity:40 60bottles/min(I) 80 120bottles/min(II) 3.Cleaness OfWashed Bottle:≥99% 4.Filling Tolerance:0 2% 5.Stoppering Qualificition:≥98% 6.Capping Qualification:≥99% 7.Power:11kw 8.Outside Dimension:9000mm×1200mm×1900mm
